Replacement parts list – Autoquip DOUBLE ARM SCISSOR LIFT TABLE User Manual
Page 38

ITEM #
DESCRIPTION
1
Base Frame Assembly
2
Top Frame and Platform Assembly
3
Inner Leg Assembly (stabilizer)
4
Outer Leg Assembly (stabilizer)
5
Lower (lifting) Arm Assembly
6
Upper (lifting) Arm Assembly
7
Roller Bearing Assembly
8
Leg Pivot PinAssembly
9
Center Axle Pin Assembly
10
Pivot Pin Assembly
11
12
Arm Hinge Pin Assembly
13
Cylinder Crosshead Assembly
14
Cylinder Base Pin Assembly
15 Hydraulic
Cylinder
16
Velocity Fuse
17
Flow Control
18
Hydraulic Reservoir (not shown)
19
Motor (not shown)
20 Pump
(not
shown)
21
Down Solenoid Valve (not shown)
22
Foot Switch / Pushbutton Control (not shown)
23
Safety Label Kit (not shown)
