15
1. The surface area where the lift will be set must be flat and level and be of sound
concrete of sufficient thickness to support the lift while loaded at full capacity.
2. For beveled toe guard models, the surface area must have a recess to allow
hydraulic lines to pass under the ends of the base frame. Hydraulic lines must be
protected or placed in a way that they are free from possible damage.
3. The base of the lift must be lagged down in the holes provided. Lag bolts should be
able to withstand 2000 lbs. minimum upward pull at each corner.
4. Shims and/or grout may be required to insure support of the entire base frame and
platform support members. DO NOT “spot” shim! Shims and/or grout must be able
to support the lift while loaded at full capacity.
5. Optional floor ramps are available. Consult a local Autoquip dealer.
INSTALLATION INSTRUCTIONS
