MNU Series Ultrasonic
I nput Registers (0x04):
Register Type Returned Data
30300 U16 Raw Distance/Level Reading (in mm)
30302 S16 Temperature Reading (in 0 C, signed)
30303-30304 U32 Calculated Reading (in selected units, no decimal)
Holding Registers (0x03):
Register Type Descrip on Value Range
40400 U16 Device Address 1 to 255
40401 U16 Units 1 to 3
40402 U16 Applica on Type 0-10
40403 U16 Volume Units 0 to 6
40404 U16 Decimal Place 0 to 3
40405 U16 Max Distance 0 to 10364 mm
40406 U16 Full Distance 0 to 10364 mm
40407 U16 Empty Distance 0 to 10364 mm
40408 U16 Sensi vity 0 to 100
40409 U16 Pulses 0 to 20
40410 U16 Blanking 0 to 10364 mm
40411 U16 Gain Control 0 to 4
40412 U16 Averaging 0 to 100
40413 U16 Filter Window 0 to 10364 mm
40414 U16 Out of Range Samples 0 to 255
40415 U16 Sample Rate 50 to 1000 msec.
40416 U16 Mul plier 1 to 1999
40417 S16 Off set +/- 10364 mm
40418-40419 reserved
40420 U16 Temperature Compensa on 0 = off , 1 = on
40421-40435 reserved
40436-40437 U32 Parameter 1 Data 0 to 100000 mm
40438-40439 U32 Parameter 2 Data 0 to 100000 mm
40440-40441 U32 Parameter 3 Data 0 to 100000 mm
40442-40443 U32 Parameter 4 Data 0 to 100000 mm
40444-40445 U32 Parameter 5 Data 0 to 100000 mm
