• FLX Specifications
Maximum Number Switching Points: 7
Resolution: +/- 1/16” (2mm)
Field Adjustable Actuation Levels: No
Maximum Length: 153 in.
Process Temperature: Class 1 Div. 2 Applications:
-40
0 to +185 0 F (-40 0 to +85 0 C)
Class 1 Div. 1 Applications:
-40
0 to +140 0 F (-40 0 to +40 0 C)
Housing Material: Die Cast
Aluminium
CSA Rating: Class 1 Div. 1
Groups C, D
Housing Rating: NEMA 4
Contact Rating:
Code A & B Switch
Max. contact capacity:
70 VA AC,
Max. switching current: 220 VAC 0.5 A, 120 VDC 0.5 A
Code C Switch
Max. contact capacity:
110 VA AC,
Max. switching current: 220 VAC 0.5 A, 115 VDC 0.5 A
