Rev. A2, 12/08 KA Series
5
Automation Products Group, Inc.
APG...Providing tailored solutions for measurement applications
Tel: 1/888/525-7300 • Fax: 1/435/753-7490 • www.apgsensors.com • [email protected]
• Specifi cations
Standard Series M Series
Contact Rating: Maximum Voltage 250 V AC or DC 250 V AC or DC
Maximum AC Current (Resistive) 6 A 6 A
(Inductive) 3 A 3 A
Maximum DC Power 75 VA (=0.3 A @ 250 V) 75 VA (=0.3 A @ 250 V)
Maximum liquid Temperature 60°C (140°F) 60°C (140°F)
Maximum pressure (at 20°C) 28 PSI 28 PSI
Minimum Fluid Specifi c Gravity 0.7 0.95
Standard Cable Length* 16 ft. 16 ft.
Switching Diff erential: Minimum 10 in. 10 in.
Maximum 50 in. 40 in.
Maximum Number of Switching Levels 4 2
Maximum Number of wires in Cable 5 2
Standard Weight Type G (black-3/4 lb.) G (black-3/4 lb.)
