Options
Part Number: PG10 - _____ - _____ - _____ - _____ - _____ - _____ - _____
A B C D E F G
Automation Products Group, Inc. www.apgsensors.com
tel. 888.525.7300 [email protected]
3
A. Common Pressure Ranges
□ 5.00 □ 50.00 □ 200.00 □ 1000 □ 5000
□ 15.00 □ 60.00 □ 300.0 □ 2000 □ 10000
□ 30.00 □ 100.00 □ 500.0 □ 3000
*Other ranges available
B. Pressure Type Table
□ PSIG▲ Gauge (up to 500 psi)
□ PSICG Compound gauge
□ PSIV Vacuum
□ PSIA Absolute
□
PSIS Sealed gauge (greater than 500 psi)
C. Port
□
F0▲ Bottom
□ F1 Rear
□
F2 Bottom with O
2
clean
□ F3 Rear with O
2
clean
□ F5 Remote transducer with mV sensor
□ F6 Rear panel mount bracket
D. Operation
(see Operation Table)
□ L0▲ (2) AA batteries; no output
□ L1-E35 4-20 mA (loop powered) output
□
L2-E35 0-2 VDC output
□
L3-E35 0-5 VDC output
□
L4-E35 External Power
□ L5-E35 RS-485; external Power (mating
connector sold separately)
□ L7 Dual lithium batteries
*Auto-off options are not available with L1-E35, L3-E35, or L4-E35
E. Relays
□
C0▲ No Solid-State Relays
□ C2 (2) Solid-State Relays with Visual Indication (L3 &
L4, L5 types only; 120 mA max, 240V AC/DC max)
□ C4 (2) SPDT mechanical relays with Visual Indication
(L1-L5 types only; 1A max @ 24 VDC)
F. Process Connection
□ P0▲ 1/4 - 18 NPTM
□
P7 7/16 - 20 SAE Male
□ P14 1/8 - 27 NPTM
□
P16 PT 1/4 (BSPM 1/4)
*Other options available
G. Accuracy
□
N0▲ ±0.25%
□ N1 ±0.25% with NIST certification
□
N2 ±0.1% with NIST certification (select ranges)
Note:
▲
Indicates this option is standard.
Operation Table
L1: 4-20 mA L2: 0-2 VDC L3: 0-5 VDC
Input Voltage
(Excitation)
9 VDC min - 28
VDC max
Battery
Powered
9-28 VDC
Input Current 3-30 mA max 6 mA max
Output
4-20 mA
±0.16 mA at set
points
Zero set point
±0.15 C with
a 2 VDC span
V0.02 VDC
0-5 VDC /
±0.05 VDC at
set points
Output/Input
2 wire
loop powered
2 wire
3 wire
Non-isolated
Resolution 14 bit 14 bit 14 bit
Protection
Reversed
Polarity
Reversed
Polarity
PG10 Accessories
Please order separately, by part number.
Description Part Number
8-pin circular mating connector (E35) 135007
8-pin circular mating connector (E35) with cable 135007-00BB (B=cable length)
Power supply w/8 pin terminal block (cable & mating connector not included) 511643
Panel mount bracket with screws 512600
