PG10 Specifications
Performance
• Accuracy (linearity & hysteresis):
±0.25% of full scale (BFSL)
±0.1% accuracy in selected ranges
• Stability – One Year Zero Drift: <±1% FS
• Thermal Zero Shift: ±0.02% FS/ ºF
• Thermal Sensitivity Shift: ±0.02% FS/ ºF
• Life: 10 million cycles minimum
• Adjustments: Auto zero, tare
Connectivity
• Output Options:
4-20 mA, 0-2 VDC, 0-5 VDC, Solid State Relays,
SPDT relays
Environmental
• Compensated Temp: 20º - 130ºF (-7º - 54ºC)
• Storage Temp: -40º - 160ºF (-40º - 71ºC)
• Operating Temp: 0º - 160ºF (-18º - 71ºC)
Certification
• NIST certification on select ranges
• CE
Electrical
• Battery Option:
(2) C alkaline; 8,000 hrs typical
(2) lithium batteries; 12,000 hrs typical
Auto-off: 2-32 minutes
Low battery detection with 25% increments
• External Power Option: 9-28 VDC
• 8-Pin Connector: IP67/68 rated bayonet
Programming
• Programmable Features:
User selectable units of measure, Max/Min
Reset & Reading, Peak-Hold, Tare, Sample
Rate, Range Adjustment, Adjustable Resolution,
Auto-Off
Physical
• Size: 5.45” x 2.25” (138.4 x 57.2 mm)
Connection: 1.59” (40.5 mm)
• Weight: 1.6 lb (725.75 grams)
• Weather-resistant injected molded phenolic
• Wetted Materials: 316L SS: up to 10,000 psi
• Display: 5 digit LCD, 0.68 in. digits
• IP65
Automation Products Group, Inc. www.apgsensors.com
tel. 888.525.7300 [email protected]
2
5.45”
138.4 mm
.25” NPT
(Standard)
1.59”
40.5 mm
2.25”
57.2 mm
8-Pin Electrical
Output Connector
.787” Hole for
Panel Mount
