Options
Part Number: PT-400 - _____ - _____ - _____ - _____ - _____ - _____ - _____ - _____ - _____
A Range B C D E F G H
A. Operation / Output
□ L1▲ 4 - 20 mA output
□ L3 0 - 5 VDC output
□ L10 0 - 10 VDC output
Modbus
□
L5 RS-485 (Modbus/RTU), 4-wire
Pressure reading only
(Approvals Pending)
□
L31 RS-485 (Modbus/RTU), 4-wire
Level calculations, tank volume
(Approvals Pending)
Range - PSI
□ 5 □ 50 □ 200 □ 1000 □ 5000
□ 15 □ 60 □ 300 □ 2000 □ 10000
□ 30 □ 100 □ 500 □ 3000
*Other ranges available
B. Units of Measure
□ psi▲ □ bar □ kPa □ kgcm 2 □ fsw
C. Pressure Type
□ A Absolute □ CG Compound Gauge
□ S▲ Sealed (100 psi or greater) □ V VAC
□ G Gauge (less than 1000 psi)
D. Electrical Connection
(Mating connector sold separately)
□ E3 4 pin bayonet PT 1H-8-4P or equiv.
□ E4 4 pin M12 micro connector.
□ E5▲ Pigtail with cable (specify cable length below)
□ E6 4 pin per DIN 43650, short can
(mating connector included)
□ E17 6 pin bayonet (PT02E-10-6P) short can
□ E18 1/2 in NPTM with 6 in flying leads, short can
□ E19 1/2 in NPTM with cable, short can
□ E36 1/2 in NPT with 6 in flying leads, long can
□ E38 1/2 in NPTM with cable, long can
□ E39 4 pin per DIN 43650 w/Solderless screw, long can
(mating connector included)
▲
This option is standard
Automation Products Group, Inc. www.apgsensors.com
tel. 888.525.7300 [email protected]
3 7/31/2013
D cont. Electrical Cable Length
□ __ Number represents cable length in ft included
on E5, E19 & E38 options.
(ex. E5-2 equals pigtail, 2 ft cable)
E. Process Connection
□ P0▲ 1/4 - 18 NPTM, 316L SS
□ P1 1/2 - 14 NPTM
17-4 SS above 500 psi, 316L SS below 500 psi
□ P5 1/4 - 18 NPTF
17-4 SS above 500 psi, 316L SS below 500 psi
□ P6 1/2 NPTF
17-4 SS above 500 psi, 316L SS below 500 psi
□ P9 H.P. SnoTrik female
(F-250C, Autoclave female) 17-4 SS above 10K
□ P30 H.P. SnoTrik male
(M-250C, Autoclave female) 17-4 SS above 10K
□ P38 1 1/2 in. tri-clover with 3/4 in. diaphragm
Available on ranges below 500 psi, 316L SS
□ P52 1 1/2 in. NPTM “flushmount
Available on ranges below 5K, 316L SS
F. Accuracy
□ N0▲ ±0.25%
□ N1 ±0.25% with NIST certification
□ N2 ±0.1% with NIST certification (select ranges)
□ N12 ±0.5% (available from 10K - 40K)
□ N13 ±0.5% with NIST certification
(available from 10K - 40K)
G. Materials
□ M1▲ 316L SS (1 to 40,000 psi)
□ M2 17-4 SS (available on ranges > 200 psi)
H. Temperature
□ S0▲ Standard: 0º - 130ºF (-17º - 54ºC)
□ S1 Extended: -40º - 180ºF (-40º - 82ºC)
M0 316 SS
□ S1 Extended: -40º - 180ºF (-17º - 54ºC)
M2 17-4PH SS
□ S4 Extended: 0º - 185ºF (-40º - 82ºC)
