ELECTRICAL PART LIST
Capacitors
Reference
Designator
Description
Part
Number
Note
C1
.0047uF, 220V
.0047uF, 1.4KV, 100/120V
120993
103447
3
C2, 3
.015uF, FILM
118091-153
C4
.01uF, CERAMIC DISC
119696-103
C5, 6
470uF, ELECTROLYTIC
110704
C7-10
1uF, ELECTROLYTIC
119942-1R0
C11-19, 22
.1uF, CERAMIC DISC
117502
C101, 117, 125, 201, 217, 225
22uF, ELECTROLYTIC
119944-220
C102, 202
2.2uF, ELECTROLYTIC
119943-2R2
C103-105, 203-205
.0068uF, FILM
118091-682
C106, 206
.33uF, FILM
123785-334
C107, 108, 121, 122, 207, 208, 221,
222
.1uF, FILM
118091-104
C109, 209
.0012uF, FILM
118091-122
C110, 126, 127, 210, 226, 227
470pF, CERAMIC DISC
119617-471
C111, 211
270pF, CERAMIC DISC
119617-271
C112, 113, 124, 212, 213, 224
.033uF, FILM
118091-333
C114, 214
.068uF, FILM
118091-683
C115, 116, 123, 215, 216, 223
.047uF, FILM
118091-473
C118, 119, 218, 219
.082uF, FILM
118091-823
C120, 220
.022uF, FILM
118091-223
SMD Capacitors
Reference
Designator
Description
Part
Number
Note
C4
.01uF, CERAMIC, CHIP
124959-103
C11-22
.1uF, CERAMIC, CHIP
124959-104
C110, 126, 127, 210, 226, 227
470pF, CERAMIC, CHIP,
10%
124956-4712
C111, 211
270pF, CERAMIC, CHIP,
10%
124956-2742
