ELECTRICAL PART LIST
Resistors (continued)
Reference
Designator
Description
Part
Number
Note
R144, 244
56k
Ω
, 1/4 Watt, 2%
117704-
1215632
R148, 248
4.12k
Ω
, 1/4 Watt, 1%
119976-
2214121
R149, 249
23.7k
Ω
, 1/4 Watt, 1%
119976-
2212372
R150, 250
30.9k
Ω
, 1/4 Watt, 1%
119976-
2213092
R160, 260
22k
Ω
, 1/4 Watt, 5%
117704-
1212235
SMD Resistors
Reference
Designator
Description
Part
Number
Note
R1, 2
2.7k
Ω
, CHIP, 5%
124895-2725
R3, 4
3.3k
Ω
, CHIP, 5%
124895-3325
R5, 6, 7, 11, 15, 118, 218
160k
Ω
, CHIP, 5%
124895-1645
R8, 9, 12, 13, 16, 101, 104
330k
Ω
, CHIP, 5%
124895-3345
R102, 103, 105, 111, 122, 124, 202,
203, 205, 211, 222, 224
2.00k
Ω
, CHIP, 1%
124894-2001
R106, 206
1,91k
Ω
, CHIP, 1%
124894-1911
R107, 207
48.7k
Ω
, CHIP, 1%
124894-4872
R108, 208
20k
Ω
, CHIP, 5%
124895-2035
R109, 126, 130, 131, 209, 226, 230,
231
23.7k
Ω
, CHIP, 1%
124894-2372
R110, 210
2.74k
Ω
, CHIP, 1%
124894-2741
R112, 114, 212, 214
13.3k
Ω
, CHIP, 1%
124894-1332
R113, 213
1k
Ω
, CHIP, 5%
124895-1025
R115, 215
10k
Ω
, CHIP, 5%
124895-1035
R116, 125, 139, 152, 216, 225, 239,
252
8.25k
Ω
, CHIP, 1%
124894-8251
R117, 128, 129, 133, 134, 217, 228,
229, 233, 234
6.81k
Ω
, CHIP, 1%
124894-6811
R119, 120, 219, 220
18k
Ω
, CHIP, 5%
124895-1835
R121, 136, 160, 221, 236, 260
22k
Ω
, CHIP, 5%
124895-2235
R123, 223
470
Ω
, CHIP, 5%
124895-4715
R127, 227
130k
Ω
, CHIP, 5%
124895-1345
R132, 141, 145, 147, 151, 153-158,
232, 241, 245, 247, 251, 253-258
6.04k
Ω
, CHIP, 1%
124894-6041
R137, 237
47.5k
Ω
, CHIP, 1%
124894-4752
R142, 242
3.01k
Ω
, CHIP, 1%
124894-3011
R143, 149, 150, 234, 249, 250
33k
Ω
, CHIP, 5%
124895-3335
R144, 244
56.2k
Ω
, CHIP, 1%
124894-5622
R146, 246
4.75k
Ω
, CHIP, 1%
124894-4751
R164, 264
26.7k
Ω
, CHIP, 1%
124894-2672
