Allen & Heath 6 GS_R24 Balanced Analogue Module User Guide
General Specifications
Number of audio channels Output
32
Number of audio channels Input
32
Nominal Signal Level
+4dBu Balanced
Analogue signal connector type
25 pin D-Sub Female (TASCAM standard pinout)
MIDI Input
5pin DIN
MIDI Output
5pin DIN
Headroom
Analogue Headroom
21dB
Channel Mapping to Interface
Console Channels
Interface Channels
Mono Channels 1-24
1-24 *
Stereo Channel 1
25-26 (L-R)
Stereo Channel 2
27-28 (L-R)
Valve Channel 1
29
Valve Channel 2
30
Main Stereo (2 Track 1) out and DIG Master L-R in.
31-32 (L-R)
GS-R24 ANALOGUE MODULE SPECIFICATIONS
* The interface sends 17-24 can be switched from Mono channels 17-24 to Aux 1-4 and Groups 1-4 in order to
record or process summed or grouped signals. This is done by pressing the under-panel switch on the GS-R24
labelled 17-24=Aux+Grp.
