6
Replacing Mains Fuse
The AC mains fuse is located on the rear of the RPS9 unit next to the AC mains connector. In the event of a mains surge or under-
rated fuse value, the mains input fuse will rupture. Switch off the power supply and remove the mains lead plug from the “AC
MAINS IN” socket on the rear of the unit.
Check the fuse and replace if necessary. Check also the AC mains input voltage setting is correct for the mains supply in your area
before switching the unit on again.
TO AVOID THE RISK OF FIRE REPLACE FUSE WITH THE CORRECT TYPE ONLY, AS
INDICATED ON THE UNIT
In the event of repeated failure of the mains fuse, consult the local dealer from where the unit was purchased.
AC MAINS VOLTAGE SETTING
FUSE RATING
220/230 VAC T 1A / 250V
100/120 VAC T 3.15A / 250V
Technical Specification
Mains Input Voltage Settings
230/220/120/100 VAC @ 47-63 Hz
Power consumption (max.)
150W
Mains Fuse Rating
100-120 V~ Use T 3.15A/250V 20mm
220-240 V~ Use T 1A/250V 20mm
Outputs
DC Voltage Rail Output Current
+16 VOLTS 2.5A Max.
-16 VOLTS 2.5A Max.
+48 VOLTS 100mA Max.
DC Output Socket Pin Connections
Pin 1 = -16 Volts
Pin 2 = AUDIO 0V
Pin 3 = CHASSIS 0V
Pin 4 = +16 Volts
Pin 5 = +48 Volts
Overall Dimensions
Front Panel Chassis (Maximum External)
19 inch 2U (482mm x 88mm) Height: 78mm including feet (3.07 inches)
Width: 400mm (15.75 inches)
Depth: 130mm (5.12 inches)
Weight: 5Kg (11 pounds)
