38
Connection Status -
z Connection – This column show current connection status. If AP already
connect to an Access Point or station, here will show the MAC address of
the associated Access Point or station. Otherwise, connection column will
show “N/A” which means no connection to any Access Point or station.
z Network Type – Here indicates the Access Point works in AP mode or
Client mode (Infrastructure mode / Ad Hoc mode)
z SSID – SSID column displays current SSID assigned to the AP
z Wireless Mode – Here show the Access Point current work in either 11b
or 11g mode
z Current Channel – This column indicates the radio channel currently in
use.
z Security - Here indicates AP security settings in client mode. Should be
either “Disabled”, “WEP” or ‘WPA-PSK”.
z Link Quality – This column shows current link quality with AP by signal
strength in 0 to 100 percentage scale.
