AirLive ®
English
85Mbps Powerline Ethernet
HP2000E
In order to start the utility, double-click the utility icon. Figure 2 shows the
main screen of the Configuration Utility. The top panel of the screen shot
shows a HomePlug device connected locally to the host computer. The
bottom panel shows four devices connected remotely to the computer
running the utility, which includes HP1000E series and HP2000E Series.
Figure 3 illustrates the scenario where a HP2000E Series device is
connected as a local device to the computer.
Figure 2: Main Screen with HP1000E device Local
Figure 3: Main Screen with HP2000E device Local
