Identifying External Components
This chapter describes the front panel, rear panel and
LED indicators of the Switch
Front Panel
The front panel of the Switch consists of 24 1000BASE-T
Gigabit Ethernet ports and LED indicators.
Front panel view of the Switch
Sixteen Gigabit Ethernet ports of 10/100/1000Mbps
Auto-Negotiation interface.
Comprehensive LED indicators that display the
conditions of the Switch and status of the network. A
description of these LED indicators follows (see LED
Indicators).
