1. Overview
AirLive BC-5010/BC-5010-IVS User’s Manual 3
Mechanical IR-Cut
Filter
Yes
Auto Iris DC-Iris Support
Viewing Angle Depend on lens
Pan/Tile Control None
Analog Video Out Yes
Video Compression
H.264 High/Main/Baseline Profile, MPEG4 Simple
Profile and MJPEG
Video Profile Yes
15 fps @ 2592 X 1920
25 fps @ 2048 x 1536
30 fps @ 1920 x1080
30 fps @ 1280 x 1024
30 fps @ 1280 x960
30 fps @ 1280 x 720
30 fps @ 720 x 480
30 fps @ 640 x 480
30 fps @ 320 x 240
Resolution and
Frame Rate
30 fps @ 176 x 144
Multi-profile streaming
Streaming over UDP, TCP, or HTTP
MJPEG streaming over HTTP (for non IE browser)
3GPP mobile view
Configurable frame rate and bandwidth
Streaming
Support both CBR and VBR
ROI Yes
AE, AWB
Saturation, brightness, sharpness, contrast, Hue
Mirror/Flip
Image Processing
Text, time and date OSD
Video
Digital Zoom 10X
G711 u-law
Audio Encoder
AMR
Audio Streaming Two-way
Audio
Audio Input/Output speaker port and microphone port
Network Ethernet
One RJ45 Port; IEEE 802.3u Compliant 10/100 Mbps
Fast Ethernet with Auto-MDIX
