1. Overview
AirLive BC-5010/BC-5010-IVS User’s Manual 2
1.2 Features
This manual will illustrate the steps of how to setup and operate this IP camera, so you’ll
also soon be enjoying the benefits of these product features:
‰ 5 megapixel high resolution CMOS sensor
‰ 0.2Lux at F1.2
‰ DC IRIS and IR-CUT Removable (ICR)
‰ Multiple Profiles Supported(H.264, MPEG4, MJPEG and 3GPP)
‰ Support 15fps at 2592x1920
‰ Two-way audio
‰ Intelligent motion detection up to 3 zones
‰ Support iSCSI, WDR enhanced
‰ HTTP/RTSP protocols selectable
‰ Image transmission using an FTP or e-mail for event
‰ Digital I/O connectors and RS-485 supported
‰ 802.3af PoE support
‰ USB wireless dongle support (with adaptor only)
‰ SD/SDHC Slot and USB slot for local storage
‰ Compatible with ONVIF standard
‰ Built-in Video Analytics (Equipped only for BC-5010-IVS)
‰ UPnP device discovery and NAT router transversal for easy installation
‰ Dynamic IP Service, DIPS®, to search your IP camera from Internet easily
1.3 Product Specification
Model BC-5010/BC-5010-IVS
Camera Type Indoor Box Type
Image Sensor 1/2.5” 5 megapixel CMOS Sensor
Sensor Resolution 2592 X 1920
C/CS Mount Lens Support
Lens Type
Removable Lens
Night Vision Built-In Removable IR Cut Filter
Max IR Distance None
Camera
Min. Illumination 0.2 LUX
