Introduction
Software Version
The software version is shown on the initial power up screen.
VUE
DRO axis availability.
Symbols within Notes
Every note is marked with a symbol on the left indicating to the
operator the type and/or potential severity of the note.
VUE Fonts
The following shows how the soft, and hard keys are represented
within the text of this manual:
„ Soft keys - SETUP soft key
„ Hard keys - ENTER hard key
This User's Manual covers the functions of the VUE for
both milling and turning applications. Operational
information is arranged in three sections: General
Operations, Mill Specific Operations and Turn Specific
Operations.
The VUE DRO is available in one, two, and three axis
form. The 3 axis VUE DRO is used through out this
manual for illustration and description of function keys.
General Information
e.g. on the behavior of the VUE.
Warning
e.g. when a special tool is required for a function.
Risk of electric shock - Caution - Damage
e.g. when opening a housing.
