7

Camera - Using Auxiliary Controls

Camera
Function

Aux
No.

Description

On/Off

Notes

BL_COMP

20

Backlight
Compensation

On/off

1

HIGH-LIGHT

21

Highlight

On/off

1, 7

SHUTTER_ADJ

22

Shutter Adjust

Inc/dec

1

SHUTTER

23

Shutter

On/off

1

WHITE_BALANCE

30

White Balance

Auto/
manual

8

RED

31

Red Adjust

Inc/dec

1, 8

BLUE

32

Blue Adjust

Inc/dec

1, 8

R_Y_HUE

33

R-Y Hue Adjust

Inc/dec

3, 8

B_Y_HUE

34

B-Y Hue Adjust

Inc/dec

3, 8

FIXED_WB

35

Fixed
White Balance

Indoor/out
door

1, 8

FACTORY_
DEFAULTS

40

Factory Default
Settings

Set/---

1,3

LL_PHASE

41

Adjust LL Phase
Delay

Inc/dec

3

SYNC

42

Sync Mode

ll/xtal

3

AGC

43

AGC

On/off

3

Note: Auto-pan is discontinued when the manual pan
control (joystick) is used.

Auto-iris and auto-focus revert to manual mode when the
manual iris and focus controls are used, respectively.

Switching to manual iris or manual focus from auto mode
reverts to the last manual setting used.

Auto-focus is activated automatically upon pan or tilt
when Auto-focus Activation is on (AUX #12).

Manual iris is activated automatically upon activating
(ON) Backlight Compensation.

Commands Using Pre-Position Controls

Receiver/Driver
Function

Pre-
Position
No.

Description

SET/SHOT

Notes

Pre-position

1-60

---

Set/show

4

Future
PP Expansion

61-100

---

----/----

--

Auto-pan
left limit

101

---

Set/show

2

Auto-pan
right limit

102

---

Set/show

2

Home Position

110

---

Recalibrate/
show

--

Disable/Enable
PP

901-960

---

Disable/
enable

6

Global Disable/
Enable PP

900

---

Disable/
enable

6

Notes:
1.

The following settings are stored with pre-position
scenes:

Pan position.
Tilt position.
Zoom position.
Focus mode AUTO/MANUAL.
Focus position for MANUAL mode.
Iris mode AUTO/MANUAL.
Iris ALC/LEVEL for AUTO mode or position for

MANUAL mode.

White Balance mode AUTO/MANUAL (color

cameras only).

Red content and Blue content for MANUAL

mode (color cameras only).

Shutter mode ON/OFF.
Shutter setting for ON mode.
Backlight compensation ON/OFF.
Highlight ON/OFF (monochrome cameras only).

2.

The following settings are stored as a default setting
in nonvolatile memory (EEPROM) on R/D board and
are used to restore settings at power-up:

Auto-pan left limit = 0 degrees.
Auto-pan right limit = 359.9 degrees.
Auto-pan speed = 30 degrees per second.
Auto-focus activation = ON.
Auto-iris activation = ON.
Auto-speed = OFF.

3.

This setting stored as a default setting in nonvolatile
memory in camera.

4.

Pre-position #1 (if set) is automatically called-up
upon power-up just after the homing sequence.

5.

Scan direction determined by last manual pan
direction.

6.

Pre-positions can be disabled such that they do not
operate during pre-position tour. They are still
available for manual call-up.

7.

Applies to monochrome cameras only.

8.

Applies to color cameras only.

Auto-Playback

Applicable only to units fitted with this feature.

Recording Playback:
1.

Position AutoDome to the point where playback is to
start.

2.

Press On, AUX 100, ENTER.

3.

Begin controlling the AutoDome.

4.

At the completion of controlling the AutoDome, press
Off, AUX 100, ENTER.

Note: If you run out of record time prior to issuing the stop record

command, the AutoDome will position itself at the beginning and
not move until the joystick is released for one second.
