6

DESCRIPTION

The TC700 Series AutoDome™ systems are quiet,
lightweight, and discreet surveillance dome systems
containing high sensitivity 1/3-inch image format full
performance monochrome or color CCD cameras with a
10:1 auto-iris, auto-focus zoom lens, a high-speed
pan/tilt, and an intelligent, integral receiver/driver. The
one-piece camera, lens, pan/tilt, and receiver/driver
module is housed in a domed enclosure. They are
available in suspended ceiling, hard ceiling recessed,
surface, and pendant mount models. Pendant mount
models are available for indoor or outdoor applications.

INSTALLATION

Attention: Installation should be performed
by qualified service personnel only in
accordance with the National Electrical Code
or applicable local codes.

Attention: L'installation doit être effectuée
uniquement par du personnel de service
qualifié conformément à la réglementation du
Code Electrique National ou à la
réglementation locale.

Achtung! Die Installation sollte nur von
qualifiziertem Kundendienstpersonal gemäß
jeweilig zutreffender Elektrovorschriften aus-
geführt werden.

Atención: La instalación de este equipo debe
ser realizada por personal capacitado, solo
en acuerdo, y en cumplimiento de normas
del "National Electric Code" (Código
Eléctrico Nacional) ó las normas del
Gobierno Nacional Local.

Removing Module From Carton

Refer to ILLUSTRATIONS for component description.

CAUTION: Keep in foil bag until grounded at
unit. Be sure to observe all safety measures
for static control when working with this unit
while out of its enclosure. Otherwise, static
damage may result.

For removal from foil bag and installation instructions,
see TC700 Series - Camera, Lens, Pan/Tilt, and
Receiver/Driver Modules Installation
under
INSTALLATION in the Installation and Operating
Instructions
supplied with the particular Backbox
Module ordered.

CAUTION: Do not handle the unit by the
circuit board because this may result in
physical damage to the unit.

OPERATION

Camera Control

These units, as shipped, are factory adjusted as
described below:

Line-lock mode enabled with zero degree phase

delay.

AGC on.
Backlight compensation off.
Electronic shutter off.
Automatic white balance on (color cameras only).

Changing Operating Modes

The AutoDome unit operating modes can be changed
using either a TC8135B Series Controller/Follower or an
Allegiant series keyboard. An Allegiant series keyboard
is required to take full advantage of all the various
features available. See Camera Commands for
description of various camera operating adjustments.

AutoDome Commands

Receiver/Driver - Using Auxiliary Controls

Receiver/Driver
Function

Aux
No.

Description

On/Off

Notes

Scan

1

Auto-pan without
limits

On/off

5

Auto-Pan

2

Auto-pan between
limits

On/off

--

Pre-Position Tour

8

--

On/off

--

Set Scan/auto-pan
speed

14

--

Inc/dec

2

Set tour period

15

Sets pause between
tour callups

Inc/dec

2

Auto-Speed

16

Enables/disables
auto-speed

On/off

2

Lens - Using Auxiliary Controls

Lens
Function

Aux
No.

Description

On/Off

Notes

Iris Control

3

--

Auto/
manual

1

Focus Control

4

--

Auto/
manual

1

Auto-iris ALC adj

10

--

Peak/ave

1

Auto-iris Level adj

11

--

Inc/dec

1

Auto-focus
Activation

12

Activates AF upon
movement

On/off

2

Auto-iris Activation

13

Activates AI upon
movement

On/off

2

Auto-Speed (AUX 16)

Auto-speed On: Issuing this command provides
variable pan speed when unit is operated from a fixed
speed location. The pan speed starts slowly and
increases as the pan control is held on. The speed
resets to slow when the pan control is released. Note:
DIP Switch S2005.4 must be in the OFF position to use
this command; see DIP Switch Settings in the applicable
Installation and Operating Instructions for additional
information.
