Page 6 Truck Loader Operator’s Manual
Assembly
1. Attach the blower discharge tube to the mounting flange
on the truck loader frame (See Fig. #3). Half of the
mounting clamp is already attached to the tube.
2. Slide the tube into the flange and tighten the bolts to
secure it.
3. Install the second half of the clamp to the tube and
flange.
4. Grease the chute to allow free rotation. Rotate the tube
360 degrees and lock it in place with the handle to
make sure it is mounted correctly.
5. Do not overtighten the bolts as it will distort the mount-
ing flanges and the discharge tube will not rotate freely.
2.5 ATTACH THE BLOWER DIS-
CHARGE TUBE (BOTH MODELS)
1. Hold one wheel to a hub and align the wheel lug holes
with the hub lug holes (See Fig. #3).
2. Thread the lug bolts into the holes and tighten to 75 ft.
lbs. Follow a star pattern when tightening lug bolts.
3. Repeat for the remaining wheel.
2.3 ATTACH THE TRAILER WHEELS
(75124)
DANGER
Do not operate this unit without the discharge correctly
installed. Flying debris can cause serious personal in-
jury.
WARNING
To prevent personal injury or property damage, sure that
all moving parts have come to a complete stop, before
servicing, adjusting or repairing.
2.2 ATTACHING THE HITCH (75124)
1. Align the hitch pole weldment with the hitch mount on
the truck loader frame (See Fig. #3). Attach the hitch
to the frame using the supplied 1/2" x 4-1/2" bolts and
nuts provided in the owners kit. Tighten to proper torque.
2. Attach the 2" adjustable coupler to the hitch using the
provided 1/2" x 4-1/2" bolts and nuts. Tighten to proper
torque.
3. Attach the hitch jack to the hitch pole weldment.
4. Attach the lighting wiring harness to the hitch pole
weldment and secure.
2.4 ATTACHING THE VACUUM HOSE
TO THE HOSE SUPPORT (BOTH
MODELS)
The vacuum hose as well as the vacuum hose support is
shipped connected to the truck loader. However, the hose
will have to be attached to the support with the provided
chain.
