P

RO

A

TTACHMENT

S

ERIES

TM

O

PERATOR

'

S

M

ANUAL

9

S

PECIFICATIONS

MODEL ----------------------------------------------------- PAS-230

Unit Length ------------------------------------------------- 1025 mm (40.4 in.)

Width -------------------------------------------------------- 250 mm (9.84 in.)

Height ------------------------------------------------------- 250 mm (9.84in.)

Weight (dry) ------------------------------------------------ 3.94 kg (8.7lb.)

Engine Type ------------------------------------------------ Air cooled, two-stroke, single cylinder gasoline engine

Bore ---------------------------------------------------------- 32.2 mm (1.27 in.)

Stroke -------------------------------------------------------- 28.0 mm (1.10 in.)

Displacement ----------------------------------------------- 22.8 cc (1.39 cu. in.)

Exhaust ------------------------------------------------------ Spark Arrestor Muffler

Carburetor -------------------------------------------------- Zama w/purge pump

Ignition System -------------------------------------------- CDI (capacitor discharge ignition)

Spark Plug -------------------------------------------------- NGK BPM-8Y Gap 0.65 mm (0.026 in.)

Fuel ---------------------------------------------------------- Mixed (Gasoline and Two-stroke Oil)

Fuel/Oil Ratio ----------------------------------------------- 50:1 two-stroke air cooled engine oil

Gasoline ----------------------------------------------------- 89 Octane unleaded. DO NOT use fuel containing methyl alcohol,

more than 10% ethyl alcohol or 15% MTBE.

Oil ------------------------------------------------------------ Power Blend

TM

Premium Universal 2-Stroke Oil

Fuel Tank Capacity ---------------------------------------- 0.58 lit. (19.6 US fl. oz.)

Starter System ---------------------------------------------- Automatic Rewind Starter

Clutch ------------------------------------------------------- Centrifugal Type

Drive Shaft -------------------------------------------------- 6.35 mm (1/4 in.) flexible shaft

Idle Speed --------------------------------------------------- 2400 - 3200

Wide Open Throttle Speed (W.O.T.) RPM ------------- 8500 - 10000
