Remove Nylon Line Head
Note: Do not disassemble nylon line head.
1. Align locking hole in upper plate with notch in edge of gear
housing and insert head locking tool (D).
2. Remove line head (E) by turning it clockwise until head is
completely off of shaft.
3. Remove locking tool (D).
Semi-automatic nylon line heads must be used only with plastic
debris shield with cut-off knife. Using nylon line heads with metal debris shield can result in trimmer damage,
caused by operation with excessive line length.
