MANUAL SAFETY SYMBOLS AND IMPORTANT INFORMATION
This symbol accompanied by the words
WARNING and DANGER calls attention to an
act or condition that can lead to serious personal
injury to operator and bystanders.
IMPORTANT The enclosed message
provides information necessary for the
protection of the unit.
NOTE This enclosed message provides tips
for use, care and maintenance of the unit.
Throughout this manual and on the product itself, you will find safety
alerts and helpful informational messages preceded by symbols or key
words. The following is an explanation of those symbols and key words
and what they mean to you.
The circle with the slash symbol means whatever is
shown within the circle is prohibited.
INTERNATIONAL SYMBOLS
Symbol
description/
application
Symbol form/
shape
Symbol
description/
application
Symbol form/
shape
Hot
Surface
Carburetor
adjustment
- Idle speed
Carburetor
adjustment
- High speed
mixture
Symbol
description/
application
Symbol form/
shape
Symbol
description/
application
Symbol form/
shape
Read and understand
Operator's Manual.
Wear eyes, ears and
head protection Emergency stop
Fuel and oil mixture
Finger Severing
Carburetor
adjustment
- Low speed
mixture
Safety/Alert
Avoid all power
lines. This unit is
not insulated
against electrical
current.
Wear hand
protection. Use
two handed.
DO NOT smoke
near fuel.
DO NOT allow
flames or sparks
near fuel.
Wear slip
resistant foot
wear.
Ignition
ON/OFF
Primer bulb
Keep bystanders away
15 m (50 ft.)
Keep feet away
from blade
Thrown
objects
Direction of
blade
Choke Control
"Cold Start"
Position
(Choke Closed)
Choke Control
"Run"
Position
(Choke Open)
PERSONAL CONDITION AND SAFETY EQUIPMENT
WARNING DANGER
Edger users risk injury to themselves and others if the edger is used improperly and or safety precautions are not
followed. Proper clothing and safety gear must be worn when operating an edger.
