Echo CH450H Owners Manual v.2 - Manual (Page 18)

14 4.5 INCH HYDRAULIC CHIPPER
Section
SPECIFICATIONS
7.1 SPECIFICATIONS
7
CH450H
DESCRIPTION ENGLISH METRIC
OVERALL SIZE 39.8" X 36.6" X 42.9" 101 X 93 X 109 CM
OVERALL WEIGHT 359 LBS. 163 KG
MAX CHIPPER CAPACITY 4.5" 11.4 cm
CHIPPER BLADES 2 REVERSIBLE (5" X 4" X 3/8") 2 REVERSIBLE (12.7 x 10.2 x .95 CM)
CHIPPING ANVIL 4.94" X 1.75" X .375 " 12.5 X 4.4 X 0.95 CM
DISC SPEED 2400 RPM 2400 RPM
DISC SIZE 14" DIA. X 1" 35.5 CM x 2.5 CM
DISC WEIGHT 49 LBS. 22.2 KG
DISCHARGE TUBE SIZE
4.5" X 9" (STANDARD) 11 x 23 CM (STANDARD)
4.5" X 4.5" (OPTIONAL) 11 x 11 CM (OPTIONAL)
DRIVE TYPE HYDRAULIC HYDRAULIC
MINIMUM HYDRAULIC
FLOW RATE
10 GAL/MIN 37.8 LITERS/MIN
MAXIMUM HYDRAULIC
FLOW RATE
14 GAL/MIN 53.0 LITERS/ MIN
HYDRAULIC PRESSURE 3000 PSI 20,680 KPa
