5 INCH PTO CHIPPER iv
TaBle oF ConTenTs
saFeTY ................................................................................................................ 1
1.1 SAFETy AlERT SyMBOl .....................................................................................1
1.2 BEFORE OPERATINg ...........................................................................................1
1.3 OPERATION SAFETy ...........................................................................................2
1.4 PTO SAFETy .........................................................................................................2
1.5 MAINTENANCE/STORAgE SAFETy ....................................................................2
1.6 SAFETy DECAl lOCATIONS ...............................................................................3
1.7 SAFETy DECAlS ..................................................................................................4
assemBlY ........................................................................................................... 5
2.1 ATTACH CHIPPER CHuTE ...................................................................................5
2.2 ATTACH DISCHARgE TuBE .................................................................................6
2.3 CONNECT PTO DRIVElINE .................................................................................7
FeaTures & ConTrols ................................................................................... 8
operaTIon ......................................................................................................... 9
4.1 STARTINg .............................................................................................................9
4.2 STOPPINg .............................................................................................................9
4.3 OPERATINg THE CHIPPER ...............................................................................10
servICe & maInTenanCe .............................................................................. 11
5.1 MAINTENANCE SCHEDulE...............................................................................11
5.2 CHIPPER BlADE MAINTENANCE .....................................................................12
5.3 REMOVINg THE BlADES ..................................................................................12
5.4 SHARPENINg THE BlADES ..............................................................................12
5.5 SETTINg THE BlADE ClEARANCE ..................................................................13
5.6 ADJuSTINg/REPlACINg DRIVE BElT ..............................................................13
5.7 REPlACINg ROTOR BEARINgS .......................................................................14
5.8 ClEARINg A PluggED ROTOR .......................................................................14
5.9 luBRICATION .....................................................................................................14
5.10 PTO luBRICATION ...........................................................................................15
TrouBlesHooTInG ........................................................................................ 16
speCIFICaTIons ............................................................................................... 17
BOlT TORQuE ...........................................................................................................18
opTIons ............................................................................................................ 19
DesCrIpTIon paGe
