5" and 8" Skid Steer Chipper
17
Section
SPECIFICATIONS
7
SPECIFICATIONS
ROTOR SPEED 2000 RPM AT 15 GPM 1500 RPM AT 25 GPM
FRAME MATERIAL
1/4" THICK STEEL CONSTRUC-
TION
1/4" THICK STEEL CONSTRUC-
TION
CHUTE SIZE 32" X 36" 32" X 36"
DRIVE SYSTEM HYDRAULICS HYDRAULICS
SKID-STEER HYDRAULICS STANDARD OR HIGH-FLOW HIGH-FLOW
CHIPPER BLADES 4 BLADES (TOOL STEEL) 4 BLADES (TOOL STEEL)
ROTOR SIZE 20" X 1-1/4", 140 POUNDS 30" X 1-1/4", 275 POUNDS
WEIGHT 1145 LBS. 1525 LBS.
CHIPPER OPENING SIZE* 5-1/2" X 7" 9" X 9"
CONTINUOUS CHIPPING SIZE* 3" (76.2 MM) DIAMETER 5" (127 MM) DIAMETER
DISCHARGE TUBE ROTATING ANGLE
RANGE
360 DEGREES 360 DEGREES
*CONTINUOUS CHIPPING SIZE RATING REFERS TO THE SUGGESTED FEEDING SIZE OF LIMBS FOR NOR-
MAL OPERATIONS. LIMBS UP TO THE CHIPPER OPENING SIZE MAY BE FED, BUT DECREASED PERFOR-
MANCE WILL OCCUR.
SPECIAL TORQUE REQUIREMENTS
LOCATION ON MACHINE HARDWARE DESCRIPTION
TORQUE
(UNIFIED INCH)
TORQUE
(METRIC)
CH500H CHIPPER BLADE
MOUNTING BOLTS
5/16" X 1-1/4" HEX HD GRADE 8
BOLTS (QTY 8)
25 FT-LBS. 34 N.m
CH800H CHIPPER BLADE
MOUNTING BOLTS
1/2" X 2-1/2" FLAT HD SKT. (QTY 12) 120 FT-LBS. 163 N.m
7.1 SPECIAL TORQUE REQUIREMENTS
