background image

KIT NO. 75983-00, SNUBBERS WITH RELAY

PART NO.

DESCRIPTION

QTY

18496-00

RELAY, PROGRAMMABLE

1

36250-00

SNUBBER HARNESS

2

2. INSTALL NEW SMARTRELAY

2.1 Remove existing SmartRelay from its cover box and

discard. As you disconnect wires,

note how they were

connected.
2.2 Attach the wires in the same way to the new

SmartRelay:

• Red wires to L, Q1-2, Q2-2, Q3-2
• White wire to M
• Green wire to I1
• Orange wire to I2
• Light green wire to I3
• Red with black tracer to I4
• Black to I5
• Green with black tracer (Chipper Harness 13545-00)

to Q1-1

• Orange with black tracer (Chipper Harness

13545-00) to Q2-1

• Red with yellow tracer to Q3-1

3.1 Connect power to chipper harness and verify Smart

Relay power-up.
3.2 Rotate rotor shaft to verify proximity sensor has power

and is within range, but not contacting the shaft. The light

on the proximity sensor should turn on and off as the shaft

completes a full revolution.
3.3 Verify that the forward, reverse, safety bar and reset/

override functions are operating.

3. VERIFY pOWER-Up

ECHO BEAR CAT

www.bearcatproducts.com

237 NW 12th Street, West Fargo, ND 58078-0849

Phone: 701.282.5520 • Toll Free: 888.645.4520 • Fax: 701.282.9522

E-mail: [email protected][email protected]
