Page 20
18
Installation
Start -> Programs -> IOGEAR Wireless -> IOGEAR
Wireless Client utility
After you launch the utility it will reside on the
windows system tray as illustrated above.
The device driver icon appears as a series of four
vertical bars. These bars provide
the following color coded indications of the received
signal strength:
·Red indicates poor quality (<5 dB)
·Yellow indicates average quality (5 to 10 dB)
·Green indicates from good (10 dB) to excellent (20
dB) quality
If you hold your mouse pointer over the icon, the
profiles, quality, ip address
display, along with the name of the current configura-
tion profile.
18.
After rebooting, The IOGEAR Client Utility icon
resides on the Desktop at the System Tray
automatically.
If wireless-reception-four-bars does not launch
and cannot get wireless connection open the
configuration utility from Windows by
performing the following steps:
