Password
6
1. Power button
2. Internet indicator
3. Wi-Fi indicator
Flashing Blue - Wi-Fi network restarting
Solid Blue - Wi-Fi network ready
4. SD card indicator
5. Battery charging indicator
Solid Green - Power on
Flashing Green - Media Hub is charging
Red - Battery low, recharge required
6. SD Card slot
7. Reset button
8. RJ-45 Ethernet port
9. USB port (also works as an emergency
charging port)
10. Micro USB charging input
Option 2: Wireless Connection
1. From the App Home screen, tap Settings.
2. Select Internet Access to bring up the
option for Wired Access (default) or
Wireless Access.
3. Select Wireless Access and tap Set.
4. Under “Configure your
Wi-Fi connection”
select a wireless
network and enter
the password (Insert
Pre-shared network
key), then tap Join to
connect.
