OUT
IN
The EQ switch allows you to fine tune the video quality of your setup to
avoid any video flickering or blinking. You may start with EQ level 0 and
increase until you see the optimized video. Wait for couple seconds
between each setting for proper adjustment.
Equalization (EQ) Adjustment Switch
LED Indication
The TMDS signal is sending from
the sender unit and received by
the receiver unit properly
STEP 5
Plug the power adapter between the wall outlet and the sender unit. Then
plug the other power between the wall outlet and the receiver unit.
FINAL STEP
Turn on your media source and display. If you don't see any audio/video or the
quality is not good, follow the steps below to adjust the EQ setting, or lower
the resolution settings as indicated in the Preparation section.
*Note: Extension range may vary with different devices and Cat 5e/6 cables
Sender unit
Receiver unit
The unit is powered
Description LED Local Unit Remote Unit
Power Orange Orange
Online N/A Green
