11
4. Connecting Audio Devices
1. The Wireless USB Device Adapter provides one 3.5mm port, as
shown in the illustration above.
5. Set-Up Complete
1. The default configuration for the external monitor connected to the Receiver Base is in
the Extend mode (an extension of the image on the computer to a second screen).
2. When the PC’s image is displayed on the display/monitor, the Wireless Connection LED
Light bar on the front panel will glow blue. The Power/Signal light will either glow green
(good signal), orange (fair signal) or red (weak signal) depending how far away the PC/PC
Adapter is from the Receiver Base. For best video image results, please position the PC/
PC Adapter close enough to the Receiver Base so that the Power/Signal Indicator Light
shows green.
Note: HD and 3.5mm options may be operated simultaneously
6. Connecting USB Devices* (Optional)
1. The Receiver Base provides one USB 2.0 port
2. Connection can be made to an External HDD’s, IOGEAR wireless keyboard etc.
*Webcam’s are not supported.
Notes: IOGEAR Wireless AV Multimedia
Keyboards with trackball make a perfect
companion: GKM561R, GKM681R,
GKM581R and GKM571R
