IOGear GHE135C User Manual
Page 12
10
Installation of Hard Drive
Step. 1 Please have the following ready
1 Phillips screw driver (not included in the package)
Remove Phillips screw from bottom
edge of side panel.
Step. 2 Remove Base
Note: For the best performance, please use the certified FireWire or USB 2.0 cable provided with this product.
If you purchased the enclosure model (GHE135C), please follow these instructions to install your 3.5" Hard Disk
Drive. OTHERWISE, PROCEDE TO PAGE 18.
WARNING: Opening ION™ Drive’s with built in Hard Drives (GHD135C40, GHD135C60, etc...) WILL VOID
YOUR WARRANTY. For assistance with your hard drive, please contact your IOGEAR service support represen-
tative.
Hardware Installation:
Attention! Please take all proper Electro Static Discharge (ESD) precautions during the installation of your new
hardware. For further information on ESD please visit http://www.esda.org.
