Installation
3
Connecting to your Console
Connecting your console to the
MiniView™ Plus.
You will need your VGA monitor, PS/2
mouse and PS/2 keyboard.
Step 1.
Connect the end of your monitor cable
into the console side of the MiniView™
Plus video port.
Step 2.
Plug in your PS/2 mouse and PS/2
keyboard into their designated ports on
the console side of the MiniView™ Plus.
2-3. Connect with CPU1
Your are here!
6-8. Audio Connections
1. Console connection
4-5. Connect with CPU2
Are you lost?
1
