Installation

4-5. Connect with CPU2

Connections to CPU1 port on
switch box.

To connect the first PC to the MiniView™ Plus,
you will need one of the two sets of IOGEAR
cables.

Step 1.

Connect the female end of your IOGEAR video
cable into the male video port on the side of the
MiniView™ Plus labeled CPU 1.

Step 2.

Plug in the PS/2 mouse and PS/2 keyboard
connectors located on the same end as the
female video connector. The cables have
images on them indicating that they are for the
keyboard or mouse.
