22 EUROLIGHT LC2412 User Manual
10. Specifications
CHANNELS 26 (24 + 2 special switchable channels)
DMX 78 out of 512 DMX channels (max. 3 DMX
channels per console-channel)
MEMORIES max. 120
CHASES max. 99
Steps max. 650, up to 99 per chase
Inputs
Analog In 1/4" TS mono jack connector, unbalanced
Level Line level
Footswitch 1/4" TS mono jack connector
MIDI In DIN 5-pole connector
Outputs
DMX512 out XLR 5-pole connector, conforms to the
DMX512/1990 standard
MIDI out DIN 5-pole connector
Analog out Sub D connector, 15-pole
Level 0/+10 V DC
Min. load impedance 600 W
Memory Card
Format PCMCIA ATA flash card
Storage capacity 4 MB
Battery type* 3 V lithium battery (e.g. CR2032)
Power Supply
Voltage
USA/Canada 120 V~, 60 Hz
Europe/U.K./Australia 230 V~, 50 Hz
Japan 100 V~, 50 - 60 Hz
General export model 120/230 V~, 50 - 60 Hz
Power consumption 37 W
Fuses 100 - 120 V~: T 1 A H 250 V
220 - 240 V~: T 500 mA H 250 V
Mains connection Standard IEC receptacle
Dimensions/Weights
Dimensions (H x W x D) approx. 4 3/16 x 17 1/2 x 11"
approx. 106 x 442 x 278 mm
Weight (net) approx. 8.38 lbs / 3.8 kg
* Caution: Danger of explosion if the battery is incorrectly replaced. You should only let qualified personnel
replace the battery. Replace only with the same type or equivalent.
BEHRINGER continuously strives to assure the highest quality standards possible. Required modifications may
be implemented without prior notice. Technical data and the appearance of the unit may deviate from the above
values and/or illustrations.
