SECTION 1 - SPECIFICATIONS
3120872 – JLG Lift – 1-1
SECTION 1. SPECIFICATIONS
1.1 CAPACITIES
Hydraulic Oil Reservoir
AC Models – 4.7 liters (5 qts. U.S.)
DC Models – 4.7 liters (5 qts. U.S.)
1.2 COMPONENT DATA
Hydraulic Pump/Electric Motor Assembly
DC Models - 12 Volt DC motor/pump
Motor - 12v - DC Standard Duty
Pump Displacement – .049 cu. in./rev.(AFC 0.8 cc/rev.)
Pump Output – 0.43 GPM @ 3500 PSI @ 11.7v-DC @
150 AMPS @ 45 Centistrokes
Pressure Relief – Adjustable Range 1500 to 5000 PSI,
Set to 2800 PSI (193 bar) at factory
AC Models - 100 Volt AC motor/pump
Motor - 100v-AC, 2HP, 2850/3450 RPM, 50/60Hz
Pump Displacement – .049 in./rev. (0.8 cc/rev.)
Pump Output – 0.43 GPM @ 3500 PSI @ 16 AMPS @
100v-AC @ 45 Centistrokes
Pressure Relief – Adjustable Range 1500 to 5000 PSI,
Set to 2800 PSI (193 bar) at factory
AC Models - 120 Volt AC motor/pump
Motor - 100/230v-AC, 1HP, 2850/3450 RPM, 50/60Hz
Pump Displacement – .049 in./rev. (0.8 cc/rev.)
Pump Output – 0.43 GPM @ 3500 PSI @ 16 AMPS @
115v-AC @ 45 Centistrokes
Pressure Relief – Adjustable Range 1500 to 5000 PSI,
Set to 2800 PSI (193 bar) at factory
AC Models - 240 Volt AC motor/pump
Motor - 100/230v-AC, 1HP, 2850/3450 RPM, 50/60Hz
Pump Displacement – .049 in./rev. (0.8 cc/rev.)
Pump Output – 0.43 GPM @ 3500 PSI @ 8 AMPS @
230v-AC @ 45 Centistrokes
Pressure Relief – Adjustable Range 1500 to 5000 PSI,
Set to 2800 PSI (193 bar) at factory
Batteries (1) – DC Models.
12 Volt – 165 Amp (min.) – Deep Cycle Marine - RV
Battery Charger – DC Models.
115/220 Volts AC – 50/60 Hz input
12 volt output w/auto charge sensing circuit.
1.3 PERFORMANCE DATA
Platform Capacity
Platform Cycle Performance
Lift Up cycle time - from stowed to maximum platform
height with maximum rated load.
Lift Down cycle time - from maximum platform height to
stowed position with maximum rated load.
Machine Weight
(with Standard Platform)
20AM-AC - 336kg (740 lbs.)
20AM-DC - 390kg (860 lbs.)
25AM-AC - 374kg (825 lbs.)
25AM-DC - 411kg (905 lbs.)
30AM-AC - 404kg (890 lbs.)
30AM-DC - 427kg (940 lbs.)
36AM-AC - 481kg (1,060 lbs.)
36AM-DC - 526kg (1,160 lbs.)
41AM-AC - 499kg (1,100 lbs.)
41AM-DC - 558kg (1,230 lbs.)
MODEL
PLATFORM CAPACITY
CE
20AM - AC & DC 160kg (350 lb.)
25AM- AC & DC 160kg (350 lb.)
30AM - AC & DC 160kg (350 lb.)
36AM - AC & DC 135kg (300 lb.)
41AM - AC & DC 135kg (300 lb.)
MAXIMUM PLATFORM
SPEEDS: (IN SECONDS)
20AM 25AM 30AM 36AM 41AM
Lift Up: 50 62 72 128 120
Lift Down: 32-42 32-42 32-42 47-57 45-55
