JLG 450A_AJ Series II Parts Manual User Manual
Page 70
2-22
SECTION 2 TURNTABLE
67
4751400
38
Flatwasher 1/4in Regular
68
4751500
12
Flatwasher 5/16in Regular
69
4751600
42
Flatwasher 3/8in Regular
70
4751800
11
Flatwasher 1/2in Regular
71
4846820
1
Weldment, Engine Tray
72
4846821
1
Mount, Motor/Generator
73
0641611
2
Bolt, 3/8in-16NC x 1-3/8in
74
3571008
1
Plate, Air
75
3571009
1
Plate, Baffle
76
3571019
1
Plate, Air Panel
77
3960438
2.35ft/.72m
Seal, Self Gripping
78
1703876
1
Decal, Engine Tray Swing
79
4922737
1
Harness, Engine Grounding
80
4711400
12
Flatwasher, 1/4in Thin
81
1703162
2
Decal - Fan Blade
82
4891600
2
Flatwasher 3/8in Hardened
83
0641612
2
Bolt 3/8in-16NC x 1-1/2in
84
4100025
1.58ft/0.49mm
Sleeve, Firberglass (SN 0300130141 to SN 0300160835)
85
1001100825
2
Strap, Ties (SN 0300130141 to SN 0300160835)
86
2720271
1.5ft/0.46m
Hose (SN 0300135293 to SN 0300160835)
87 to 89
Not Used
Ref
Note: Arctic Package Items 90 - 94 Not Shown - Used on
Machines with Arctic Package Only
90
3980007
1
Seat, Battery
91
1702941
1
Decal - Battery Heater
92
1702942
1
Decal - Engine Block Heater
93
2580024
1
Heater, Battery
94
2580054
1
Heater, Engine Block
Ref
CATERPILLAR ENGINE INSTALLATION
0275872
Ref
Machines without Arctic Package
F
0275874
Ref
Machines with Arctic Package
G
101
0100011
AR
Compound, Locking
102
0100020
AR
Sealant
103
Not Used
104
0641406
AR
Bolt, 1/4in-20NC x 3/4in (Not Shown)
105
0641418
2
Bolt, 1/4in-20NC x 2-1/4in
106
0641610
2
Bolt, 3/8in-16NC x 1-1/4in
107
0642010
1
Bolt, 5/8in-11NC x 1-1/4in
108
0902443
1
Bracket, Hood Latch Mount
109
0902444
1
Bracket, Hood Support
110
1320022
5
Clamp, Fuel Line
111
1320223
1
Clamp, J Clip 1/2in (Not Shown)
112
1701505
1
Decal, Diesel Fuel (Not Shown)
113
Not Used
114
2180536
1
Fitting, Straight Barbed
115
2220250
1
Fitting, Reducer
116
2220313
1
Fitting, Elbow Barbed
FIGURE 2-7. USA BUILT MACHINES/CATERPILLAR ENGINE INSTALLATION (WITH
ELECTRICAL DRIVEN COOLING FAN) (WITHOUT UGM) (CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
