Section 9 - Specifications
9-5
31200149
Dimensions
Overall Height.................................................................................95.4 in (2423 mm)
Overall Width.....................................................................................99 in (2515 mm)
Cab Width............................................................................................37 in (940 mm)
Track Width ....................................................................................82.2 in (2088 mm)
Wheelbase ......................................................................................128 in (3251 mm)
Length at Front Wheels ................................................................183.5 in (4661 mm)
Overall Length (less Forks) ..........................................................212.6 in (5400 mm)
Ground Clearance ...............................................................................17 in (432 mm)
Turning Radius Over Tires .......................................................... 141.3 in (3589 mm)
Turning Radius at Forks .............................................................. 182.4 in (4633 mm)
Maximum Gross Vehicle Weight (no attachment) ..................... 22,685 lb (10.290 kg)
Maximum Front Axle Weight (no attachment)
(boom level and fully retracted) ...................................................... 9,528 lb (4322 kg)
Maximum Rear Axle Weight (no attachment)
(boom level and fully retracted) .................................................... 13,157 lb (5968 kg)
Maximum Ground Bearing Pressure
13.00 x 24
Air Filled........................................................................136 lb/in² (9,6 kg/cm²)
Foam Filled .................................................................178 lb/in² (12,5 kg/cm²)
15.50 x 25
Air Filled........................................................................136 lb/in² (9,6 kg/cm²)
Foam Filled .................................................................183 lb/in² (12,9 kg/cm²)
370/75-28
Air Filled.......................................................................... 91 lb/in² (6,4 kg/cm²)
Foam Filled ................................................................... 114 lb/in² (8,0 kg/cm²)
