Page 256
ELECTRICAL
G5-19A/G6-23A
31200194
10-22
Item
Part Number
Qty.
Description
Rev.
4923506
1
MAIN HARNESS, (includes all items)
I
1
70020911
3
FEMALE FASTON
2
1001116995
3
FEMALE FASTON COVER
3
1001104519
90
FEMALE FASTON
5
1001116986
1
4 WAY CONNECTOR
6
1001116991
1
2 WAY CONNECTOR
8
7029671
12
2 WAY CONNECTOR
9
7029672
11
SWITCH CONNECTOR
10
1001116716
3
FEMALE FASTON
12
7029642
1
4 WAY KEY CONNECOTOR
13
7029643
1
6 WAY KEY CONNECTOR
14
1001118383
2
GIANT FEMALE FASTON
15
7029645
4
FEMALE TERMINAL
16
7029646
1
6 WAY CONNECTOR
17
1001107854
1
CONTACT
18
7029647
5
WIRE SEAL
20
1001103012
1
4 WAY SUPERSEAL CONNECTOR
21
1001116698
1
SEAL PLUG
24
1001118378
10
MATE-N-LOCK MALE TERMINAL
25
91504093
6
SEALING PLUG
26
7029653
8
MATE-N-LOCK 15 WAY CONNECTOR
28
7029655
3
MATE-N-LOCK FEMALE CONNECTOR
29
7029656
2
THIMBLE
30
NSS
AR
HEAT SHRINK TUBE
31
1001116692
53
TERMINAL
32
83481301
38
SEALING PLUG
33
4460814
1
CONNECTOR
37
4460761
1
CAP
38
91504092
1
PIN
39
1001116693
44
MALE CONTACT
40
1001116934
1
CONNECTOR
41
1001116936
1
CONNECTOR
42
1001116943
1
CONNECTOR
43
80484072
1
CONNECTOR
44
80604020
1
CONNECTOR
47
7029664
8
MALE CONTACT
48
1001116941
1
CONNECTOR
50
250176
1
CONNECTOR
51
7029675
1
WIRE SEAL
52
7029676
8
INTERFACE SEAL
53
1001118382
17
SOCKET TERMINAL
54
7029678
1
CONNECTOR PLUG
56
91364013
1
CONNECTOR
57
4460746
4
TERMINAL
58
7029679
4
WIRE SEAL
59
7026425
1
CONNECTOR
60
80363179
1
LOCK CONNECTOR
61
4461164
1
8 POS CONNECTOR
62
7029681
1
12 POS CONNECTOR
