FRAME & ATTACHING PARTS
G5-19A/G6-23A
31200194
1-4
Figure 1-1 Frame Shrouding & Trim
Item
Part Number
Qty.
Description
Rev.
0275028
1
ENGINE HOOD INSTALLATION, (includes items 1 thru 17)
A
1
1671260
1
HOOD ASSY, (includes items 22 thru 24)
A
2
1671177
1
ENGINE PANEL HOOD
3
0903274
1
BRACKET
4
3575643
1
SUPPORT PLATE
5
8000382
1
HOOD LATCH
6
8000801
1
HOOD LOCK
7
4806433
2
HINGE
8
4160213
1
GAS SPRING
9
2014226
6.4 M
RUBBER SEAL
10
0760810
11
HEX HD CAPSCREW, 8-1.25X20mm, GR 8.8
11
0761010
2
HEX HD CAPSCREW, 10-1.50X20mm, GR 8.8
12
3290605
3
HEX LOCK NUT, M6X1
13
3290805
2
HEX LOCK NUT, M8X1.25
14
4811700
3
FLAT WASHER, 6mm
15
4811900
11
FLAT WASHER, 8mm
16
4812000
2
FLAT WASHER, 10mm
17
5220800
1
RIPP NUT, 8mm
22
2520136
1
GRILL
23
4340868
1
HOOD SUPPORT
24
4806444
1
PLATE
30
0275255
1
REAR COVER PANEL, (includes item 33)
A
33
3380687
1
REAR PANEL
35
2360729
1
FRAME, (G5-19A), (Before S/N 1160002168)
2360778
1
FRAME, (G5-19A), (S/N 1160002168 & after)
2360663
1
FRAME, (G6-23A)
36
3575641
1
PANEL SUPPORT
37
Ref
HEADLIGHT ASSY, (see Figure 10-1 for details)
38
3140007
2
MIRROR, (G5-19A)
3140007
1
MIRROR, (G6-23A)
39
1781813
8
CAB MOUNT
40
4806626
4
BUSHING
41
8000565
4
WASHER
42
8000567
4
RUBBER MOUNT
43
0712029
4
HEX HD CAPSCREW, GR 10.9, (torque to 111 ft-lb [150 Nm])
44
3292001
4
HEX NUT, M20X2.5
46
0761012
2
HEX HD CAPSCREW, 10-1.50X25mm
47
8003392
1
CABLE SET, GROUND CONNECTION
48
4812000
2
FLAT WASHER, 10mm
49
Ref
CAB,
54
80363195
1
MIRROR
55
3841634
1
MIRROR ATTACH BAR
56
3291601
2
HEX NUT, M16X2
57
4812300
2
FLAT WASHER, 16mm
58
3292001
2
HEX NUT, M20X2.5
59
4812500
2
WASHER, 20mm
60
0100011
AR
LOCTITE, #242
