Page 117
Section 9 - Specifications
9-3
31200192
Capacity at Maximum Forward Reach
G5-19A ....................................................................................... 2,200 lb (998 kg)
G6-23A ..................................................................................... 2,500 lb (1134 kg)
Reach at Maximum Height
G5-19A ...........................................................................................2.63 ft (80 cm)
G6-23A ................................................................................................3 ft (91 cm)
Break-out Force with Standard Bucket
G5-19A ............................................................................ 7,823 lb-force (34,8 kN)
G6-23A .......................................................................... 12,400 lb-force (55,2 kN)
Towing Capacity
G5-19A ..................................................................................... 5,000 lb (2268 kg)
G6-23A ..................................................................................... 6,600 lb (2993 kg)
Carriage Rotation .................................................................................... 134 degrees
Dimensions
Overall Height
G5-19A .....................................................................................78.7 in (2000 mm)
G6-23A .....................................................................................92.7 in (2354 mm)
Overall Width
G5-19A .....................................................................................83.9 in (2131 mm)
G6-23A .....................................................................................91.9 in (2335 mm)
Cab Width............................................................................................35 in (890 mm)
Track Width
G5-19A .....................................................................................64.3 in (1633 mm)
G6-23A .....................................................................................74.5 in (1893 mm)
Wheelbase
G5-19A ...................................................................................105.9 in (2690 mm)
G6-23A ...................................................................................114.2 in (2900 mm)
Length at Front Wheels
G5-19A ...................................................................................148.5 in (3773 mm)
G6-23A ...................................................................................163.1 in (4144 mm)
Length at Fork-Holder Plate
G5-19A ...................................................................................171.8 in (4364 mm)
G6-23A ...................................................................................193.5 in (4915 mm)
Ground Clearance
G5-19A .......................................................................................12.3 in (312 mm)
G6-23A .......................................................................................17.2 in (439 mm)
