6-18 740AJ 3121161
SECTION 6 HYDRAULIC
FIGURE 6-5. HYDRAULIC DIAGRAM LIST
ITEM # PART NUMBER QTY. DESCRIPTION REV.
Ref Note: Diagrams with asterisk (*) are shown in the preceding
pages. Information on diagrams not shown is available from
JLG Service/Parts Departments.
2792589 Ref Air Compressor Hydraulic Diagram
Ref Tow Package Hydraulic Diagram Options:
2792571 Ref Prior to SN 0300136124
1001107290 Ref SN 0300136124 to SN 030183033
Ref Drive Hydraulic Diagram
2792364* Ref Prior to SN 0300137975
2792710* Ref SN 030037975 to Present
Ref Oil Cooler Hydraulic Schematic
Ref Deutz Engine
1282665 Ref Prior to SN 0300137666
Not Required Ref SN 0300137666 to Present
1283309 Ref Ford & GM Engine
Ref Standard Hydraulic Diagram
2792528* Ref Fenner & Haldex Brand Auxiliary Pump
1001143189* Ref Bucher Brand Auxiliary Pump
Ref Standard Hydraulic Schematic
2792535 Ref Prior to SN 0300137975
1001108855 Ref SN 0300137975 to Present
Ref Tilt Sensor Installation Options:
1001093187 Ref Prior to SN 0300112885
1001094557 Ref Adapter, Pressure Tap
