2-132 740AJ 3121161
SECTION 2 TURNTABLE
26 3900322 2 Screw, Shoulder
27 4060802 1 Guard, Switch (Not Shown - Located at Platform)
28 4240018 AR Tie-Strap
29 4340738 1 Support, Idler Pulley
30 4360336 1 Switch, Toggle (Not Shown - Located at Platform)
31 4568734 2 Spacer, Tube (Idler Pulley Non-Grooved)
32 4568735 1 Spacer, Tube (Idler Pulley Grooved)
33 4711400 1 Flatwasher 1/4in Narrow
34 4711700 2 Flatwasher 7/16in Narrow
35 4740397 1 Spacer
36 4751000 2 Flatwasher #10 Wide
37 4751600 3 Flatwasher 3/8in Wide
38 4751800 1 Flatwasher 1/2in Wide
39 4891500 1 Flatwasher 5/16in Hardened
40 4891600 4 Flatwasher 3/8in Hardened
41 4892000 2 Flatwasher 5/8in Hardened
FIGURE 2-29. 2500W GENERATOR INSTALLATION - FORD MACHINES (ANSI & CSA SPEC
ONLY) (OPTIONAL) (SN 0300077500 TO SN 030185827) (CONTINUED)
ITEM # PART NUMBER QTY. DESCRIPTION REV.
