9-2
SECTION 9
RECOMMENDED SERVICE
PARTS STOCK
VARIABLE PARTS
4360578
Switch, Limit (Figures 1-1 & 3-6)
1
1001112758
Module (Chassis) (Figure 1-7)
1
1001112757
Module, B.L.A.M. (Figure 2-1)
1
7027795
Module, Deutz Engine (Figure 2-6)
1
7003655
Element, Caterpillar Engine Air Filter (Figure 2-5)
12
7026811
Element, Caterpillar Engine Oil Filter (Figure 2-5)
12
7026830
Element, Caterpillar Engine Fuel/Water (Figure 2-5)
12
7016331
Element, Deutz TD2011 Engine Oil Filter (Figure 2-6)
12
7016328
Element, Deutz TD2011 Engine Fuel (Figure 2-6)
12
7003655
Element, Deutz TD2011 Engine Air Filter (Figures 2-6)
12
70024190
Element, Deutz TCD2.9L4 Air Filter (Figure 2-7)
12
7026031
Sensor, Proximity (Figure 2-14)
1
1001119509
Module, Ground Control (Figure 2-17)
1
1001119512
Module, Repeater (Figure 2-17)
1
4360469
Switch, Key (All Specs except CE Spec) (Figure 2-17)
1
4360470
Switch, Key (CE Spec) (Figure 2-17)
1
3740080
Relay (Headlights/Chassis Illumination Lights Options) (Figure 2-18)
1
3740080
Relay (110V/220V Generator Options) (Figure 2-21)
1
4360336
Switch, Toggle (Generator Options) (Figures 2-21, 2-22 & 2-23)
1
4360070
Circuit Breaker 15 Amp (Machines with 7500W Generator)
(Figures 2-22 & 2-23)
1
4000008
Switch, Jib Lock Proximity (Figure 3-6)
1
4360527
Switch, Cable Break (Figure 3-6)
1
4360543
Sensor, Boom Length (Figure 3-6)
1
1001133329
Sensor, Angle Indicator (Figure 3-6)
1
1001118971
Switch, Angle Indicator (Main Boom Protractor) Proximity (Figure 3-6)
1
1001135479
Switch, Angle Indicator (Jib Rotate) Proximity (Figure 3-6)
1
1001120104
Switch, Jib Telescope Proximity (Figure 3-6)
1
1001119262
Module, Jib Control (Figure 3-10)
1
1001117174
Footswitch Kit (Figure 4-1)
1
4360336
Switch, Toggle (Floodlights Options) (Figure 4-1)
1
4360057
Switch, Limit (Soft-Touch System Option) (Figure 4-3)
1
1600343
Module, Platform Control (Figure 4-4)
1
4360522
Switch, Push Button (Chassis Worklights Option) (Figure 4-4)
1
1001109475
Circuit Breaker 16 Amp (CE Spec Machines) (Figure 7-3)
1
1001109482
Circuit Breaker 30mAmp (CE Spec Machines) (Figure 7-3)
1
MODEL 1500SJ
The following list will service one machine (built to current production per date on the front cover) with emergency repair
parts which can be installed in the field. Parts from the list should be replaced when inventory is depleted to keep service
parts stock supplied. For further information, contact your JLG dealer or the JLG Industries Parts Department.
Part Number
Description
Qty./Machine
