JLG E45A_AJ ANSI Parts Manual User Manual
Page 182
8-4
3120766
SECTION 8
DECALS
S
E
C
T
I
O
N
8
D
E
C
A
L
S
28
1704431
Decal - Battery Charger Led Indicator (S/N 49542 to
Present Only)
1
29 to 30
Not Used
31
0860520
Box, Manual Storage
1
32
1060279
Lanyard
1
33
0641408
Bolt 1/4”-20NC x 1”
1
34
Not Used
35
4711400
Flatwasher
6
36
3311405
Locknut 1/4”-20NC
5
37
1701500
Decal - Lift
4
38
1701509
Decal - Manual
1
39
Decal - Danger Options:
1
1702279
Prior to S/N 47974
1703813
S/N 47974 to Present
40
Not Used
41
1703804
Decal - Crushing Hazard
6
42 to 46
Not Used
47
1702265
Decal
1
48 to 49
Not Used
50
1702300
Decal - Tie Down
4
51
Not Used
52
Not Available
Decal - Bar Code
1
53
1702688
Decal - 500 LBS. Max Capacity
1
54
Decal - Tire Load Options:
4
1703488
E45A
1704445
E45AJ
1703488
M45A
1704445
M45AJ
1704727
E40AJP
1704752
E40AJPnarrow
1704727
M40AJP
1704752
M40AJPnarrow
55 to 61
Not Used
62
1702774
Decal - JLG Lift
A/R
63
Decal Options:
2
1702773
A & AJ Models (JLG)
1704200
AJP Models (Jib Plus)
64
1704252
Decal - Key, Main Terminal Box
1
65
1701645
Decal - 500 LBS. Max Capacity
1
66
1701502
Decal - Hydraulic Oil Level High
1
67
1701503
Decal - Hydraulic Oil Level Low
1
68 to 69
Not Used
70
Decal - Generator Danger Options:
A/R
Not Required
E45 & E40
0
1704286
M45 & M40
2
71
Decal - Fuel Options
Not Required
E45 & E40
0
1701505
M45 & M40
1
72
Not Used
FIGURE 8-1. DECALS INSTALLATION - STANDARD (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
