7-22 3120766
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
601D Connector, Strain Relief Options: 1
4460071 110V GFI (ANSI)
4460071 220V GFI (ANSI)
Supply Locally 220V GFI (ANSI Export)
601E Plug, Male Options : 1
4460205 110V GFI (ANSI)
4460233 220V GFI (ANSI)
Supply Locally 220V GFI (ANSI Export)
601F Harness (Main Boom) Options: 1
4921593 Harness (M45 & E45 ANSI) 1/A
4921569 Harness (M40 & E40 ANSI) 1/A
4921595 Harness (M45 & E45 ANSI Export) 1/A
4921571 Harness (M40 & E40 ANSI Export) 1/A
Electrical Cable Options:
1060494 M45 & E45 ANSI (12/3) 32ft//9.75m
1060494 M40 & E40 ANSI (12/3) 30ft//9.14m
1060461 M45 & E45 ANSI Export (12/3) 32ft//9.75m
1060461 M40 & E40 ANSI Export (12/3) 30ft//9.14m
601G 4460205 Plug, Male 1
601J Harness (Tower Boom) Options: 1
4921592 Harness (M45 & E45 ANSI) 1/A
4921568 Harness (M40 & E40 ANSI) 1/A
4921594 Harness (M45 & E45 ANSI Export) 1/A
4921570 Harness (M40 & E40 ANSI Export) 1/A
Electrical Cable Options:
1060494 M45 & E45 ANSI (12/3) 42ft/12.8m
1060494 M40 & E40 ANSI (12/3) 38ft/11.6m
1060461 M45 & E45 ANSI Export (12/3) 42ft/12.8m
1060461 M40 & E40 ANSI Export (12/3) 38ft/11.6m
601K 4460134 Connector, Female 1
602 2920095 Platform Worklights Harness (Includes Light and
Wire Only) 2
602A 4460428 Connector, Strain Relief 1
TOOLS Ref.
701 7002821 Crimper (For Wire to Pin/Socket Connections) 1
702 7002823 Extractor (For Removal of Pin/Socket from Connec-
tors) 1
703 4460467 Extractor, Pin (Blue 16-18 Gauge) (For Removal of
Pin/Socket from Connectors) 1
4460510 Extractor, Pin (Yellow 12-14 Gauge) (For Removal of
Pin/Socket from Connectors) 1
704 7002828 Stripper, Wire 1
705 2901443 Analyzer, Machine (Not Shown) 1
FIGURE 7-4. HARNESS COMPONENTS INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
