SECTION 3 - MACHINE CONTROLS AND INDICATORS
3-10 – JLG Lift – 3121170
6. Main Telescope
Allows extension and retraction of the main boom.
7. Lights (If Equipped)
Operates accessory light packages if the machine is so
equipped.
8. Jib Lift
Push forward to lift up, pull back to lift down. Variable lift
speed is accomplished by using the Function Speed Control.
9. Soft Touch Override Switch (If equipped)
Enables the functions that were cut out by the Soft Touch
system to operate again at creep speed, allowing the opera-
tor to move the platform away from the obstacle that caused
the shutdown situation.
NOTE: The Jib Swing function is not operable when the Capacity Select
control is in the 1000 lb. (454 kg for ANSI markets and 450 kg
for CE and Australia markets) position.
10. Jib Swing
Allows the operator to swing the jib to the left or right.
11. Tower Boom Lift
Allows raising and lowering of the tower boom by activating
the tower lift and telescope cylinders as dictated by the
Boom Control System.
12. Soft Touch Indicator (If Equipped)
Indicates the Soft Touch bumper is against an object. All
controls are cut out until the override button is pushed, at
which time controls are active in the Creep Mode.
13. Platform Rotate
Allows the operator to rotate the platform to the left or right.
