SECTION 2 TURNTABLE
FIGURE 2-24. GENERATOR INSTALLATION - FORD MACHINES BUILT MARCH 1995 TO PRESENT
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0255227 GENERATOR INSTALLATION Ref. 8/G
1 3580250 Pulley, Crankshaft 1
2 2460011 Generator Assembly 1
7003657 Control Box Assembly 1
Note: Replacement 110V Control Box comes
wiith 2 std Receptacles p/n 4460190. Optional
Industrial Twist Lock Receptacles p/n 4460027
must be ordered separately.
7010699 Meter 1
7012558 Generator Assembly 1
3 3580134 Pulley 1
4 2860012 Key, Woodruff 1
5 0902104 Bracket, Generator Mounting 1
6 0200530 Arm, Adjusting 1
7 4564417 Tube, Spacer 1
8 0641508 Bolt 5/16"-18NC x 1" 1
9 4751500 Flatwasher 5/16" 1
10 4761500 Lockwasher 5/16" 1
11 0641612 Bolt 3/8"-16NC x 1 1/2" 3
12 4751600 Flatwasher 3/8" 3
13 4761600 Lockwasher 3/8" 3
14 3311601 Nut 3/8"-16NC 1
15 4566650 Tube, Spacer 1
16 0701015 Bolt 10mm - 1.5 x 35mm 2
17 4812000 Flatwasher 10mm 2
18 4832000 Lockwasher 2
19 3580239 Pulley, Idler 1
20 4740275 Washer 1
21 0480090 Belt, Generator 1
22 0100011 Loctite (Not Shown) A/R
23 0721004 Bolt #10-24NC x 1/2" 2
24 3311001 Nut #10-24NC 2
25 4751000 Flatwasher #10 6
26 4761000 Lockwasher #10 2
27 3251476 Nameplate, Generator 1
28 Cable, Electrical -12/4 Options: 3ft/.9m
1060012 Prior to S/N 60653
1060515 S/N 60653 to Present
29 4460071 Connector, Strain Relief 1
30 0960238 Bushing 1
31 3300048 Nut, Conduit 1
32 4460023 Connector, Strain Relief 1
33 to 35 Not Used
36 4070585 Shim (.010) A/R
37 4070586 Shim (.005) A/R
38 4070587 Shim (.002) A/R
39 0641608 Bolt 3/8”-16NC x 1” 1
