SECTION 2 TURNTABLE
FIGURE 2-22. GENERATOR INSTALLATION - FORD ENGINE MACHINES BUILT PRIOR TO MARCH
1995 (OPTIONAL)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
GENERATOR INSTALLATION Ref.
0239244 Prior To May 1991 Ref. I
0251947 May 1991 To March 1995 Ref. C
1 4060696 Shield, Heat 1
2 0641508 Bolt 5/16"-18NC x 1" 3
3 4761500 Lockwasher 5/8" 4
4 V-Belt Options: 1
0480037 (Prior to May 1987)
0480048 (May 1987 to March 1995)
5 3580134 Pulley (Part of Item 6) 1
6 2460011 Generator and Control Box Assembly 1
7003657 Control Box Assembly 1
Note: Replacement 110V Control Box comes
wiith 2 std Receptacles p/n 4460190. Optional
Industrial Twist Lock Receptacles p/n 4460027
must be ordered separately.
7010699 Meter 1
7012558 Generator Assembly 1
7 4340565 Support, Adjustable 1
8 4751500 Flatwasher 5/16" 1
9 4843156 Support Weldment 1
10 4564123 Tube, Spacer A/R
11 0701021 Bolt, Metric 10mm x 65mm 2
12 4564329 Tube, Spacer 1
13 4740116 Lockwasher, Metric 10mm 4
14 0361704 Bar, Mounting 1
15 0701023 Bolt, Metric 10mm x 70mm 4
16 0721004 Screw, Machine #10-24NC x 1/2" 2
17 4751000 Flatwasher #10 4
18 4761000 Lockwasher #10 2
19 3311001 Nut #10-24NC 2
20 Not Used
21 3251476 Decal - On/Off 1
22 1060012 Cable, Electrical - 12/4 A/R
23 4460134 Connector (Not Shown - Located at Generator) 1
24 4460071 Connector (Not Shown - Located at Ground Control
Box)
1
25 3300048 Locknut, Conduit (Not Shown - Located at Ground
Control Box)
1
26 0960238 Bushing (Not Shown - Located at Ground Control
Box)
1
27 4460023 Connector, Terminal (Not Shown - Located at
Generator Control Box) 1
28 2860012 Key 1
29 4564328 Tube, Spacer 1
30 0681610 Bolt 3/8"-16NC x 1 1/4" (Grade 8) 2
31 4761600 Lockwasher 3/8" A/R
32 4751600 Flatwasher 3/8" 3
